Specifications

·        Pneumatically driven electronically controlled system

·        Built-in ventilator, LED displayscreen

·        With 1 patient circuit for adult (Option:patient circuit for children).

·        4-tube flow meters, O2 & N2O ;0.1 L/Min~ 10 L/Min;

·        Two vaporizer,Enflurane/Isoflurane/Sevoflurane; (Option: Halothane)

·        Oxygen Flush: 25~75 L/Min;

·        Respiration Mode: IPPV, SIPPV, SIMV, Manu

·        Tidal Volume: 50~1500 mL;

·        I:E: 1:1.5, 1:2.0,1:2.5, 1:3, 1:4;

·        Respiration Frequency: 4~40 bpm;

·        Ptr: -10~10 hPa;

·        CO2 absorber capacity: 1 kg

·        Alarm parameter: upper /lower limit of airway pressure, tidal volume exceed limitation, no tidal volume output, apnea, AC power malfunction, battery lowpower

Loop part

·        Integrated design, integrated breathingcircuit

Evaporator

·        High-precision single evaporatorconfiguration, enflurane or isoflurane or Sevflurane or Haloflurane

·        Concentration adjustment range: 0.5 ~ 5%VOL

·        Evaporator flow, pressure, andautomatictemperature compensation function

·        Self-locking feature

Configuration

·        Vaporizer: two vaporizer,Enflurane/Isoflurane/Sevoflurane(Option: Halothane)

·        Anesthesia gas concentration range:0.5~5%

·        Soda lime absorption system： resistant to high temperature of 176 degrees Celsius.

·        ISO certificates approved
