Features:

- Easy maintenance design with auto waste collection

- High test speed, ideal for medium to high amount samples laboratory

- Fully automatic operation for ready-to-test

- Internal calibration for sensitivity of strips

- Cold light source facility with long life and high stability

- Rs232 serial interface to host PC/LIS, Barcode reader optional

- URIT UQ-10 & UQ-11 Urinalysis Control

Specifications:

- Parameters: pH, Nitrite, Ascorbic Acid, Protein, Specific Gravity, Blood, Glucose,Bilirubin, Urobilinogen, Ketone, Leucocytes

- Measurement Principle: Dual wavelength reflectance method

- Measuring Wavelength: 3 LED Wavelength (550,620,720nm)

- Reaction time: 65 seconds

- Throughput: 520 samples /hour

- Display: LCD screen

- Memory Capacity: 5000 results (3000 results with barcode)

- Strip: URIT 10G/11G/ 14G urine reagent strips,optional with

11F/12F/14F urine reagent strips

- Interface:Serial port(RS232), parallel port (For external printer), PS/2(For barcode reader)

- Work condition: Environmental Temperature: 15-30℃, RH:20%~80%

- Power supply: 100~240V AC,50/60Hz

- Dimension: 390mm x 340mm x 290mm
