Model

BK-EL10A

BK-EL10B

BK-EL10C

BK-EL10D

Measurement Channel

Vertical 8 optical channels

Plate Type

96-well microplate

Wavelength Range

400～750nm

340～850nm

Filter

Standard 4 wavelengths of 405,450,492,630nm(BK-EL10A,BK-EL10B,BK-EL10C)

Standard 5 wavelengths of 340,405,450,492,630nm(BK-L10D) Optional:Up to 10 wavelengths.

Reading Range

0.0 00～3.000Abs

Linear Range

0.000～3.000Abs

0.000～4.000Abs

0.000～4.500Abs

Resolut

001Abs

0.000～3.500Abs

Repeatability

CV≤1.0%

Stal

≤±0.005Abs

CV≤0.2%

Sernsitivity

≥0.01 mg/L

Channel Differenc

≤0.02Abs

≤±0.003Abs

Vibration Plate Function

3 kinds of vibration plate function,adjustable 0~255s(BK-EL10A,BK-EL10B,BK-EL10C)

5 kinds of vibration plate function,adjustable 0~255s(BK-EL10D)

Incubation Function

Time Range:0~60min Temp.Range:RT+4℃~50℃(Only for BK-EL10D)

Software

(Standard)

Detection Mode

Single/double wavelength

Qualitative

Open CUT-OFF decision formula,supporting the input of judgment condition,validity condition input,grey area setting and other functions

Quantitative

Support linear,Semi-log,natural logarithm,log-log,point-to-point,four-parameter equati and other quantitative analysis fitting algorithms

Others

Display

10.1 inch color touch capacitive screen(BK-EL10A,BK-EL10D)

10.1 inch resistive touchscreen(BK-EL10C)

Operating Mode

Touch screen operation,equipped with capacitive stylus,support for external keyboard and mouse(BK-EL10A,BK-EL10D)

Printer(Optional)

BK-EL10A,BK-EL10D:Support external USB,RJ45 network port and other universal interface printer(A4 printer can be optional)

BK-EL10B:Workstation software supports normal printer(A4 printer can be optional)

BK-EL10C:Workstation software supports normal printer(A4 printer and thermal printer can beoptional)

Interface

USB2.0*4,RJ45 network port*1,RS-232*1(BK-EL10A,BK-EL10D)

RS232 serial port(BK-EL10B)

RS-232*2(standard RS232 to USB cable)(BK-EL10C)

Power Supply

AC100~240V,50/60Hz

Instrument Size(W*D*H)

450*320*300mm

450*320*190mm

450*320*300mm

495*340*370mm

Package Size(W*D*H)

540*400*460mm

585*425*405mm

610*440*475mm

Net/Gross Weight

13/15kg

10/12kg

11/13kg

12/14kg
