Features
1. 1 robotic arm,2 pipetting probes(10~1000μl).
2. 4 unit 96 well microplates (independent incubating).
3. 1 unit reader&washer (auto reading and washing).
Software Module
User-friendly Windows system; LIS system available.
Sample Module
Hitech teflon coating probe to prevent cross contamination.
Sample & Reagent & Dilution Rack Module
Original sample tubes available; Rack positions programmable.
Microplate Reader & Washer Module
Modularized automatic control reading and washing system.
Technical Specifications
|
Mode |
BIOBASE2000 |
|
|
Sample Unit |
Sample Racks |
Standard 192 sample positions (expandable,up to 552) |
|
Pipetting |
10~1000μl |
|
|
Dispensing System |
2 aspirating and dispensing probe(X-Y-Z movement) |
|
|
Reagent Unit |
Reagent Position |
23 reagent racks,editable |
|
Pipetting Range |
10~1000μl,1μl stepping |
|
|
Pipetting Precision |
(100μl)CV≤0.5% |
|
|
Washing Unit |
Dispensing Time |
4 minutes to whole 96 well microplates |
|
Washing Probes |
Two line 8-nozzle manifolds |
|
|
Wash Containers |
Cleaning fluid(15L),waste water (25L),Buffer 1(5L),Buffer 2(2L),Buffer 3(2L), Buffer 4(2L),with liquid level-sensing,liquid shortage and full alarm |
|
|
Waste Containers |
25L with waste full sensor |
|
|
WashingResidual |
<2μ |
|
|
Reading Unit |
Reading Channels |
8 independent photometric channels,mono and dichromatic reading |
|
Absorbance |
0.0~3.0 OD |
|
|
Spectral Range |
A00~700nn |
|
|
Optical Filters |
2 standard filters (450,630nm);2 more on request (405nm/450nm/492nm/630nm) |
|
|
Reading Accuracy |
±1%from 0~1.5OD,±2%from 1.5~3.0 OD |
|
|
Incubation Unit |
Incubators |
4 independent units |
|
Temperature Range |
RT to 45℃ |
|
|
Temperature Accuracy |
±0.5℃ |
|
|
Data Management |
Software System |
Above Windows 7 system |
|
LIS System |
Bi-direction,support HL7 protocol |
|
|
Results |
Absorbance and results reviewable by software |
|
|
Printer |
External optional |
|
|
Working Conditions |
Power Supply |
AC220V±10%50/60Hz;110V±10%60Hz,400W |
|
Temperature |
10~30℃ |
|
|
Humidity |
30%~80% |
|
|
Size &Weight |
External Size(W*D*H) |
1235*705*875mm |
|
Net Weight |
146kg |
|
|
Package Size(W*D*H) |
1380*860*1435mm |
|
|
Gross Weight |
220kg |
|
