Features
1. 49 Sample positions.
2. 56 Reagent positions.
3. 120 Reaction cuvettes.
4. 200 tests per hour.
5. Probe with anti-collision function, liquid level dectection function.
ReactionTray
37±0.2℃,real-time monitor.
Mixer Probe
Teflon coating to avoid cross contamination.
Reagent Tray
2~8℃ cooling for 24 hours.
Sample Probe
Liquid level sensor function.
Anti-collision function.
Reagent volume real-time detection.
Software
User-friendly software.
Washing Probe
Independent 5-step washing system.
Technical Specifications
|
Model |
BK-280 |
|
|
Overall Performance |
Throughput |
200 Tests/hour |
|
Analysis Method |
End-point,Fixed-time,Rate(Kinetic),Turbidimetry |
|
|
Certificates |
CE,FDA,ISO9001,ISO13485 |
|
|
Sample & Reagent System |
Sample Positions |
49 sample positions |
|
Reagent Positions |
56 reagent positions |
|
|
Sample Volume |
2~70μl |
|
|
Reagent Volume |
20~350μl |
|
|
Probe |
Teflon coating,with anti-collision function,liquid level detection function |
|
|
Probe Washing |
Automatic washing interior and exterior |
|
|
Reagent Cooling |
Refrigerated tray with independent switch |
|
|
Reaction System |
Temperature Control |
37±0.2℃ |
|
Cuvettes |
120 reusable cuvettes,optical length 6mm |
|
|
Mixer Probe |
Independent stirring |
|
|
Washing |
Automatic cuvettes washing |
|
|
STAT Function |
YES |
|
|
Optical System |
Light Source |
12V/20W halogen lamp |
|
Spectrophotometry |
Post-spectral spectrophotometry |
|
|
Wavelength |
340,405,450,480,505,546,570,600,630,700,750,800nm |
|
|
Absorbance |
0~3.0Abs |
|
|
Calibration &QC |
Calibration |
Linear:K factor,1-point,2-point and multipoint linear Non-Linear:Spline,Polygon,Logit-4P,Logit-5P |
|
Quality Control |
Real-time QC,Westgard multi rule,Cumulative sum check, Twin Plot(2D),Daily QC,Monthly QC |
|
|
Data Management |
Software |
Windows 7/8/10,32 or 64 bit |
|
LIS System |
Bi-direction,support HL7 protocol |
|
|
Interface |
LAN port access |
|
|
Printer |
External optional,multiple reporting mode available |
|
|
Working Conditions |
Power Supply |
AC220V±10%50/60Hz,110V±10%60Hz,300W |
|
Temperature |
15~30℃ |
|
|
Water Consumption |
Deionized water:5L/H |
|
|
Humidity |
40%~85% |
|
|
Size &Weight |
External Size (W*D*H) |
950*600*515mm |
|
NetWeight |
75kg |
|
|
Package Size (W*D*H) |
1130*735*1040mm |
|
|
Gross Weight |
135kg |
|
