Features
1. 9.7-inch color touch LCD screen,easy to operate,display all parameters and histograms on the same screen.
2. Fewer samples are required for testing: whole blood≤12μl, pre-diluted≤20μl.
3. 60 samples/hour.
4. 21 parameters +3 histograms.
5. It can be turned on continuously for 24 hours.
6. Automaticall clean the sampler,counting pool and pipeline after startingup
7. Buit-in thermal printer,external printer can be connected.
8. Electrical impedance method,cyanide-free detection of HGB.
9. Fully intelligent blockage removal and alarm function.
10. Both automatic calibration and manual calibration are available.
11. Counting Mode:Venous,capilary,prediluted.
12. Support LIS system.
Technical Specifications
|
Model |
BK-3200 |
|||||
|
Throughput |
60 samples/hour |
|||||
|
Principle |
Impedance for WBC differentiation and WBC/RBC/PLT count;Colorimetric method for HGB |
|||||
|
Channels |
2 |
|||||
|
Parameters |
21 parameters(including WBC,Mid#,Lym#,Gran#,Mid%,Lym%,Gran%,RBC,HGB,HCT, MCV,MCH,MCHC,RDW-SD,RDW-CV,PLT,MPV,PDW,PCT,P-LCR,P-LCC) |
|||||
|
Histograms |
3 histograms (including WBC,RBC,PLT histograms) |
|||||
|
Sample Volume |
Whole blood:12μl,Prediluted:20μl |
|||||
|
Calibration |
Manual,auto calibration |
|||||
|
Counting Modes |
Venous,capilary,prediluted |
|||||
|
Printing Model |
Auto print,manual print |
|||||
|
LIS |
Support Bi-directional LIS |
|||||
|
Language |
Chinese,English,Spanish,French,Russian,Ukrainian |
|||||
|
Reagent |
Diluent 10L,Hemolytic agent 250ml,Probe cleanser:50ml |
|||||
|
Data Input |
9.7-inch touch screen,mouse,keyboard (optional) |
|||||
|
Output |
Internal printer,support external printer |
|||||
|
Printer Paper |
57*30mm |
|||||
|
Interface |
4 USB ports,network port,RS232 serial port |
|||||
|
Storage |
100.000 results with histogram |
|||||
|
Unclog |
High voltage burn,reverse high-pressure flush |
|||||
|
Work Temperature |
15-30℃ |
|||||
|
Power Supply |
100-240 AC,50/60Hz,150VA |
|||||
|
Relative Humidity |
30%~85% |
|||||
|
Atmospheric Pressure |
70.0kPa-110.0kPa |
|||||
|
Carry-Over Rate |
Parameter |
WRC |
RBC |
HGB |
PLT |
|
|
CV |
≤ 1.5% |
≤ 1% |
≤ 1% |
≤3% |
||
|
Background |
Parameter |
WBC |
RBC |
HGB |
HCT |
PLT |
|
Background |
≤ 0.03*109/L |
≤ 0.03*1012/L |
≤1g/L |
≤0.5% |
≤10*109/L |
|
|
Linearity |
Parameter |
Measurement range |
CV |
|||
|
WBC |
(0.5~10.00*109)/L (10.10~99.9*109)/L |
(±0.5*109)/L ±5% |
||||
|
RBC |
(0.05~1.00*1012)/L (1.01~9.99*1012)/L |
(±0.05*1012)/L ±5% |
||||
|
HGB |
(2~70g)/L (71~300.0g)/L |
(±2.0g)/L ±2% |
||||
|
PLT |
(10~100*109)/L (101~999*109)/L |
(±10.0*109)/L ±8% |
||||
|
Precision |
Paiameter |
Repeatabilit |
Measurement range |
|||
|
WBC |
≤6.0% |
(3.5~9.5×109)/L |
||||
|
RBC |
≤3.0% |
(3.8~5.8×1012)/L |
||||
|
HGB |
≤2.5% |
(415~175g)/L |
||||
|
PLT |
≤10.0% |
(125-350×109)/L |
||||
|
HCT |
≤3.0% |
35%~50% |
||||
|
External Size(W*D*H) |
295*467*418mm |
|||||
|
Packed Size(W*D*H) |
Instrument:404*564*616mm; Reagent:340*340*340mm |
|||||
|
Net Weight |
19 kg |
|||||
|
Gross Weight |
Instrument:31kg; Reagent:13 kg |
|||||
