Product Features：

l  Made strictly according to ISLH Recommended Reference Procedure for the Enumeration of Particles in Urine;

l  Un-centrifuged urine samples at cutoff concentration level of 3-5cell/µl are detectable;

l  Automatic sampling system;

l  Automatic recognition, classification and quantitation of urine formed elements;

l  Precise erythrocytes morphological analysis helps to determine the source of hematuria;

l  Real whole view-field microscopic images of urine formed elements are presented;

l  Automatic notice of verification and on-screen verification, no additional microscopic review needed;

l  Characteristic parameters of urine formed elements are available for further clinical research;

l  Standardized and confirmatory analysis report with both images and diagrams available;

l  Self-learning ability continuously improves the recognition accuracy;

l  Unique morphological quality control available;

l  Unidirectional or bidirectional interface with LIS/HIS;

l  Software and language upgrades by USB stick;

l  Data receivable from automatic urine analyzers, customized for medium- sized laboratories.

Technilcal Parameters

Auto-detected Urine Formed Elements:  Normal red blood cells (NRBC), Abnormal red blood cells (ARBC), White blood cells (WBC), Casts (CAST), Epithelial cells( EPI), Yeast (YST), Crystals (CRYS), Mucus (MUC) and Bacteria (BAC). Further sub-classification is available with manual on-screen verification!

Magnification:  Standard 10X & 40X images

Memory:  Min. 200,000 results (including all images captured)

Min. Sample volume:  2.0 ml

Max. Sample loading number:  5 racks of 5 tubes

Throughput:  Up to 80 tests / hour (763A), up to 100 tests / hour (763C), up to 120 tests / hour (763B)

Built-in Computer:  Yes

Built-in Barcode reader:  Yes

Printer:  Laser, external, optional

Interfaces:  USB, RS232, LAN

Dimensions (main unit):  765 x 685 x 475mm (L x D x H)

Weight (main unit):  57kg

Power (main unit):  100-240V~50/60Hz, 450VA
