Performance characteristics

l  8.4 "touch screen LCD display, displaying all parameters and three histograms on the same screen without the need for page flipping.

l  Full Chinese color operation interface, no need for external computer, graphical button operation, supports mouse and keyboard.

l  Multiple online fast Chinese input and output of hospital and patient information.

l  Built in high-speed thermal printer, with multiple Chinese report formats for measurement results to choose from.

l  Can be connected to an external workstation to print standard Chinese reports

Technical parameter

Complete machine function：Fully automatic white blood cell three part grouping, with 23 parameters (including three color histograms of WBC, RBC, and PLT).

Working principle：Electrical impedance method for counting and cyanide free (environmentally friendly) colorimetric method for measuring hemoglobin.

Test parameters：WBC，LYM#，MID#，GRAN#，LYM%，MID%，GRAN%，RBC，HGB，HCT，MCV，MCH，MCHC，RDW-SD，RDW-CV，PLT，MPV，PDW，PCT，P-LCR and WBC、 RBC、PLT three histograms

Injection method：There are three options available: venous blood, anticoagulant peripheral blood, and  pre diluted peripheral blood.

Detection speed：≥70 tests/hour, can be continuously turned on for 24 hours.

Sample usage：Anticoagulated whole blood (venous blood) ≤ 9.6 μ l, anticoagulated peripheral blood ≤ 9.6 μ l, pre diluted peripheral blood ≤ 20 μ l.

Working mode：Double counting cell, fully automatic injection, automatic measurement throughout the   detection process, and equipped with a built-in diluter, no need for external dilution. The host automatically adds hemolytic agent and performs secondary dilution automatically

Drainage method：Various intelligent automatic blockage removal functions such as soaking, forward and reverse flushing, real-time monitoring, etc., with incomplete blockage monitoring function.

Alarm function：Fully automatic system diagnosis, with self checking function, fault alarm prompt, insufficient reagent remaining and other alarm prompts.

Automatic maintenance：The instrument automatically performs maintenance, cleaning, and upkeep. After turning on and off, the cleaning solution automatically soaks the pipeline  to reduce the chance of blockage.

Result storage：Automatically store all parameters and three histograms of over 100000 samples, and can be infinitely expanded via USB.

Calibration method：The three measurement modes have independent automatic calibration and manual  calibration, supporting national standard calibration materials and quality control material control.
